ZF 6HP26 / 6HP28 / 6HP26X / 6HP28X - 29 elements

A complete set of friction discs for ZF 6HP26, 6HP28, 6HP26X and 6HP28X series automatic transmissions. The product is dedicated to all couplings (A, B, C, D, E) in the above-mentioned cases of boxes, ensuring full compatibility and high quality of workmanship.

Technical specifications:

• Manufacturer: ZF
• Condition: New
• Transmission type: 6HP26 / 6HP28 / 6HP26X / 6HP28X
• Disc type: Double-sided friction discs
• Number of elements in the set: 29

Kit contents:

• 10x A&D clutch friction disc:
  • Outer diameter (OD): 187.3 mm
  • Thickness (TH): 2.1 mm
  • Number of internal teeth (TE): 30
• 12x B&C clutch friction disc:
  • Outer diameter (OD): 187.3 mm
  • Thickness (TH): 1.6 mm
  • Number of internal teeth (TE): 30
• 7x Clutch Friction Disc:
  • Outer diameter (OD): 130.8 mm
  • Thickness (TH): 1.6 mm
  • Number of internal teeth (TE): 30

Compatibility:

The kit fits ZF gearboxes with the following codes:

• 6HP26: 1068 010 112, 120, 123, 134, 151, 153, 154, 155, 166, 167, 168, 169, 170, 171, 172, 173, 174, 182, 183
• 6HP26X: 1068 020 060, 061
• 6HP28: 1068 040 001, 002, 008, 009, 010, 011, 012, 013, 014, 015, 016, 018, 024, 026, 027, 028, 029, 030, 031, 032, 035, 036, 037, 041, 045, 046, 047, 048, 051, 052, 053, 054, 055, 056, 057, 058, 059, 060, 061, 062, 063
• 6HP28X: 1068 050 001, 002, 003, 004, 007, 008, 009, 010, 011, 012, 013, 014, 015, 016, 019, 020, 021, 022, 023, 024, 025, 026, 027, 028, 029, 031, 033, 034, 035, 036, 041, 042, 043, 044, 045, 046, 047, 048, 049, 050, 051
• 6HP28AF: 1084 030 014, 018

Key features:

• Original ZF quality for long service life
• Precise fit to the gearbox specification
• Improved gear shift smoothness and overall transmission performance
• Reliability under extreme operating conditions
• Easy installation as part of standard service procedures

Summary:

The ZF 6HP26/6HP28/6HP26X/6HP28X is a reliable and cost-effective solution for workshops and services that specialize in automatic transmission repairs. Thanks to its high-quality workmanship and full compatibility with the original specifications, the product ensures long-term and failure-free operation of the drive train.
